H1P045L pump Danfoss H1-P-045-L seriesH1 axial piston pump

H1P045L pump Danfoss H1-P-045-L seriesH1 axial piston pump

NOMINAL DISPLACEMENT:45/53/60/68/69/78/89/100/115130/147/168/210/250mL/r
RATED SPEED:2200-3500r/min
SPEED RANGE:500-4000r/min
MAXIMUM PRESSURE:42-45MPa
RATED PRESSURE:20-30MPa

H1 P045L pump H1 series variable displacement pumps are compact units with high power for closed circuit systems
Danfoss H1 Series swash plate variable displacement axial piston pump.
The working volume of the pump is 45 cm3,pump shaft rotation left hand and max RPM 3500r/min.The H1 Series pump models have a built-in charge pump
Which supply oil to the system and cool it, as well as to regulate the fluid flow.
Ifthe input shaft is at the top, the housing pressure must maintain at 1 bar during operation. The housing must always filwith hydraulic fluidDiferent control systems are available for the pump such as hydraulic, electro-hydraulic proportional, discrete, mechanical.
Danfoss Hi series pumps use in HST machines, Such as bulldozer, excavator, pipelayer, mini-loader, snowcat, as well as in drilling rigs

Code de modèle complet

H1-P-045-R-A-A-F2-C1-C-D8-F-G4-H3-F-02-F-02-B-P-24-P1-NNN-NNN
H1-P-053-L-A-A-A5-C1-N-D8-F-G1-H5-L-35-L-35-B-P-24-P6-NNN-NNN
H1-P-053-R-A-A-A5-C1-N-D8-F-G1-H3-L-30-L-30-N-E-36-PN-NNN-NNN
H1-P-060-L-A-A-A3-C2-N-F5-H-G1-H6-L-33-L-33-C-P-28-PN-NNN-NNN
H1-P-060-L-A-A-A5-C2-N-F4-H-F1-H6-L-33-L-33-C-M-28-PN-NNN-NNN
H1-P-078-L-A-A-A3-C2-N-D8-H-F1-H5-L-35-L-35-C-P-24-PN-NNN-NNN
H1-P-078-R-A-A-A3-C2-N-D6-H-G1-NN-L-35-L-35-F-L-24-PN-NNN-NNN
H1-P-089-R-B-A-A5-C2-N-D3-H-G9-H6-L-35-L-35-M-M-24-PN-NNN-NNN
H1-P-100-R-B-A-A5-C3-N-D8-H-G9-H6-K-48-K-48-M-P-24-PN-NNN-NNN
H1-P-115-R-B-A-A5-C2-N-D3-G-G2-E5-L-30-L-30-L-M-24-PN-NNN-NNN
H1-P-130-R-B-A-A5-C1-B-D8-G-G3-H4-L-35-L-35-L-P-24-PN-NNN-NNN
H1-P-147-R-D-A-A3-C3-B-D3-G-G3-NN-L-25-L-25-L-D-20-PN-NNN-NNN
H1-P-147-R-D-A-A3-C3-N-D3-G-G2-H4-L-30-L-30-L-M-24-PN-NNN-NNN
H1-P-165-R-D-A-A3-C2-N-D8-G-G2-H4-L-33-L-33-L-P-24-PN-NNN-NNN
H1-P-210-R-A-A-A5-C2-N-D8-C-F8-E1-L-35-L-35-R-P-24-PN-NNN-NNN

H1P045 Danfoss original brand new hydraulic closed-loop pump, used in forestry machinery and equipment, logging machines, tree felling machines, afforestation machines, stable quality, low failure rate and long service life. Advantageous product, welcome to inquire.

Better parts company specialize in research and development,production and sales of hydraulic products.We have more than 8 years experience focusing on the overseas Market.

Our main products is hydraulic pump,motor,valve,gear box ,gear pump,spare parts,ect.Involved in hydraulic brands:Rexroth,Parker,Eaton-Vickers,Linde,Sauer-Danfoss and so on.We always adhere to the "High Quality,best service,competitive price ”product concept.

Welcome new and old customers from all over the world to contact us for future business relationship and mutual sucess
