BETTER PARTS Machinery Co., Ltd. bbonniee@163.com 86--13535077468
تفاصيل المنتج
مكان المنشأ: الصين
اسم العلامة التجارية: REXROTH
رقم الموديل: Rexroth A10VSO 18/28/45/71/100/140
شروط الدفع والشحن
الحد الأدنى لكمية: 1pcs
الأسعار: NIGOTIATION
تفاصيل التغليف: صندوق قياسي
وقت التسليم: 15 يوم عمل
شروط الدفع: ر/ر
القدرة على العرض: 1000/شهر
الاستخدام: |
النفط، مضخة المكبس الهيدروليكي |
Appliion: |
النظام الهيدروليكي، المضخات الهيدروليكية، exvaor |
بناء: |
مضخة المكبس، المضخات الهيدروليكية |
قوة: |
هيدروليكي |
ضغط: |
الضغط العالي |
وقود: |
الزيت الهيدروليكي |
نظرية: |
مضخة دوارة، مضخات هيدروليكية |
قياسي أو غير قياسي: |
معيار |
لون: |
طلب العميل ، تخصيص |
مادة: |
الحديد الزهر |
اسم المنتج: |
مضخات هيدروليكية |
ضمان: |
1 سنة |
حالة: |
100% جديد، OEM جديد ومبتكر |
ميزة: |
كفاءة عالية ، حياة طويلة |
يكتب: |
مضخة هيدروليكية ريكسروث |
طلب: |
النظام الهيدروليكي |
الاستخدام: |
النفط، مضخة المكبس الهيدروليكي |
Appliion: |
النظام الهيدروليكي، المضخات الهيدروليكية، exvaor |
بناء: |
مضخة المكبس، المضخات الهيدروليكية |
قوة: |
هيدروليكي |
ضغط: |
الضغط العالي |
وقود: |
الزيت الهيدروليكي |
نظرية: |
مضخة دوارة، مضخات هيدروليكية |
قياسي أو غير قياسي: |
معيار |
لون: |
طلب العميل ، تخصيص |
مادة: |
الحديد الزهر |
اسم المنتج: |
مضخات هيدروليكية |
ضمان: |
1 سنة |
حالة: |
100% جديد، OEM جديد ومبتكر |
ميزة: |
كفاءة عالية ، حياة طويلة |
يكتب: |
مضخة هيدروليكية ريكسروث |
طلب: |
النظام الهيدروليكي |
Features
Variable displacement pump with axial piston rotary group of swashplate design for hydrostatic drives in open circuit.
Flow is proportional to the drive speed and displacement.
Flow can be infinitely varied by controlling the swashplate angle.
Hydrostatically unloaded cradle bearing.
Port for measurement sensor on high pressure port for all sizes with port plate 22 and 32.
Low noise level.
Increased functional reliability.
High efficiency.
Good power to weight ratio.
Universal through drive for all sizes with port plate 22 and 32.
Optional pulsation damping.
|
Size
|
45
|
71
|
100
|
140
|
180
|
|||
|
Displacement
geometric, per revolution |
Vg max
|
cm³
|
45
|
71
|
100
|
140
|
180
|
|
|
Nominal pressure
|
pnom
|
bar
|
280
|
280
|
280
|
280
|
280
|
|
|
Maximum pressure
|
pmax
|
bar
|
350
|
350
|
350
|
350
|
350
|
|
|
Maximum speed
|
at Vg max
|
nnom
|
rpm
|
1800
|
1800
|
1800
|
1800
|
1800
|
|
Flow
|
at Vg max and nnom
|
qV nom
|
l/min
|
81
|
128
|
180
|
252
|
324
|
|
at Vg max and n = 1500 rpm
|
qV 1500
|
l/min
|
67.5
|
106.7
|
150
|
210
|
270
|
|
|
Power
|
at qV nom and pnom
|
P
|
kW
|
38
|
59.7
|
84
|
118
|
151
|
|
at qV 1500 and pnom
|
P 1500
|
kW
|
67.5
|
106.7
|
150
|
210
|
270
|
|
|
Torque
|
at Vg max and pnom
|
M
|
Nm
|
200
|
317
|
446
|
624
|
802
|
|
Weight (approx.)
|
m
|
kg
|
30
|
47
|
69
|
73
|
78
|
|
BETTERPARTS is an enterprise specializing in research, development, manufacturing and after-sales hydraulic pump pressure brand products. Having been engaged in the injection molding machine/die-casting industry/hydraulic station/engineering machinery/hydraulic pump industry for many years, with rich industry experience, we have created a group of professional after-sales teams and won a good reputation in the hydraulic industry for the company.
The company has a team of talents with rich professional knowledge and practical experience, adhering to the principle of "customer first, high-quality service, and abiding by contracts". With high-quality products, good reputation, and high-quality service, the products are best-selling in nearly 30 provinces, cities, autonomous regions, as well as exported to countries such as Malaysia, India, Southeast Asia, Australia, etc. Sincerely cooperate with domestic and foreign merchants for win-win cooperation, common development, and create brilliance together!
|
R902469087
|
AA10VSO140LA6S/32R-VSB22U99
|
|
R902492308
|
AA10VSO140LA5D/32R-VPB22U99
|
|
R902464819
|
AA10VSO140LA6D/32R-VKD72U99
|
|
R902465294
|
AA10VSO140LA6D/32R-VKD72U99E
|
|
R902482706
|
AA10VSO140LA6D/32R-VPB22U68
|
|
R902444124
|
AA10VSO140LA6D/32R-VPB32U99
|
|
R902490763
|
AA10VSO140LA6DG/32R-VSD72U17E
|
|
R902490762
|
AA10VSO140LA6DG/32R-VSD72U99E
|
|
R902494538
|
AA10VSO140LA6DS/32R-VKD72U99SO413
|
|
R902453223
|
AA10VSO140LA7D/32R-VPB32U99
|
|
R902551907
|
AA10VSO140LA7S/32R-VSB22U00E
|
|
R902453128
|
AA10VSO140LA5D/32R-VPB12N00
|
|
R902477642
|
AA10VSO140LA5DS/32R-VSB22U99
|
|
R902460051
|
AA10VSO140LA5S/32R-VPB12N00
|
|
R902452754
|
AA10VSO140LA6D/32R-VPB12N00
|
|
R902513427
|
AA10VSO140LA6DG/32R-VPB32U00E
|
|
R902460112
|
AA10VSO140LA6DG/32R-VPB32U99
|
|
R902544311
|
AA10VSO140LA6DG/32R-VSB22U00E-SO52
|
|
R902551880
|
AA10VSO140LA6DG/32R-VSD72U00E
|
|
R902467497
|
AA10VSO140LA6DS/32R-VSB22U99
|
|
R902463149
|
AA10VSO140LA6DS/32R-CPB22U99-SO52
|
|
R902463150
|
AA10VSO140LA6DS/32R-CPB32U99-SO52
|
|
R902577437
|
AA10VSO140LA6DS/32R-VPB12N00
|
|
R902449952
|
AA10VSO140LA6DS/32R-VPB12N00
|
|
R902577436
|
AA10VSO140LA6DS/32R-VPB12N00
|
|
R902577432
|
AA10VSO140LA6DS/32R-VPB12N00*GOEU*
|
|
R902454865
|
AA10VSO140LA6DS/32R-VPB22U99
|
|
R902518672
|
AA10VSO140LA6DS/32R-VPB32U00E
|
|
R902544614
|
AA10VSO140LA6DS/32R-VPB32U00E
|
|
R902514720
|
AA10VSO140LA6DS/32R-VPB32U68E
|
|
R902454562
|
AA10VSO140LA6DS/32R-VPB32U99
|
|
R902490866
|
AA10VSO140LA6DS/32R-VSB22U52
|
|
R902489612
|
AA10VSO140LA6DS/32R-VSB22UB9
|
|
R902513638
|
AA10VSO140LA6DS/32R-VSB32U00E
|
|
R902532674
|
AA10VSO140LA6DS/32R-VSB32U00E*GO2EU*
|
|
R902468668
|
AA10VSO140LA6DS/32R-VSB32U99
|
|
R902467373
|
AA10VSO140LA6DS/32R-VSB32UB7
|
|
R902460767
|
AA10VSO140LA6DS/32R-VSB32UB9
|
|
R902491914
|
AA10VSO140LA6DS/32R-VSB32UE1Z-SO52
|
|
R902455281
|
AA10VSO140LA7D/32R-VPB12N00
|
|
R902577722
|
AA10VSO140LA7DG/32R-VPB12N00
|
|
R902489776
|
AA10VSO140LA7DG/32R-VPB22U99-SO52
|
|
R902460113
|
AA10VSO140LA7DG/32R-VPB32U99
|
|
R902534704
|
AA10VSO140LA7DG/32R-VSB22U00E
|
|
R902563862
|
AA10VSO140LA7DG/32R-VSB22U00E-SO52
|
|
R902563863
|
AA10VSO140LA7DG/32R-VSB22U00ECSO52
|
|
R902564242
|
AA10VSO140LA7DS/32L-VPB22U04ECS4093
|
|
R902578328
|
AA10VSO140LA7DS/32R-VPB12K01E-SO52
|
|
R902577438
|
AA10VSO140LA7DS/32R-VPB12N00
|
|
R902577439
|
AA10VSO140LA7DS/32R-VPB12N00
|
|
R902577440
|
AA10VSO140LA7DS/32R-VPB12N00
|
|
R902577955
|
AA10VSO140LA7DS/32R-VPB12N00
|
|
R902449698
|
AA10VSO140LA7DS/32R-VPB12N00
|
|
R902467375
|
AA10VSO140LA7DS/32R-VPB22U04
|
|
R902564243
|
AA10VSO140LA7DS/32R-VPB22U04ECS4093
|
|
R902471291
|
AA10VSO140LA7DS/32R-VPB22U99
|
|
R902490864
|
AA10VSO140LA7DS/32R-VPB22UB7
|
|
R902455280
|
AA10VSO140LA7DS/32R-VPB32U99
|
|
R902465382
|
AA10VSO140LA7DS/32R-VSB12N00
|
|
R902572351
|
AA10VSO140LA7DS/32R-VSB22U00E
|
|
R902492689
|
AA10VSO140LA7DS/32R-VSB22U52
|
|
R902466254
|
AA10VSO140LA7DS/32R-VSB22U99
|
|
R902511694
|
AA10VSO140LA7DS/32R-VSB32U00E
|
|
R902545806
|
AA10VSO140LA7DS/32R-VSB32U00E
|
|
R902532675
|
AA10VSO140LA7DS/32R-VSB32U00E*GO2EU*
|
|
R902566715
|
AA10VSO140LA7DS/32R-VSB32U00E*QDP1*
|
|
R902465071
|
AA10VSO140LA7DS/32R-VSB32U99
|
|
R902475115
|
AA10VSO140LA7DS/32R-VSB32UB9
|
|
R902493514
|
AA10VSO140LA7S/32R-VPB12N00E
|
|
R902572434
|
AA10VSO140LA8D/32R-VSB32UB3E
|
|
R902493980
|
AA10VSO140LA8DS/32L-VPB22U04-S2888
|
|
R902530643
|
AA10VSO140LA8DS/32L-VPB22U04E-S4093
|
|
R902537163
|
AA10VSO140LA8DS/32L-VPB22U04ECS4093
|
|
R902549730
|
AA10VSO140LA8DS/32L-VPB22U04ECS4093
|
|
R902577441
|
AA10VSO140LA8DS/32R-VPB12N00
|
|
R902489021
|
AA10VSO140LA8DS/32R-VPB22U04
|
|
R902493979
|
AA10VSO140LA8DS/32R-VPB22U04-S2888
|
|
R902530640
|
AA10VSO140LA8DS/32R-VPB22U04E-S4093
|
|
R902549731
|
AA10VSO140LA8DS/32R-VPB22U04ECS4093
|
|
R902537162
|
AA10VSO140LA8DS/32R-VPB22U04ECS4093
|
|
R902492975
|
AA10VSO140LA8DS/32R-VPB22U99
|
|
R902451153
|
AA10VSO140LA8DS/32R-VPB32U99
|
|
R902535423
|
AA10VSO140LA8DS/32R-VSB22U00E
|
|
R902469026
|
AA10VSO140LA8DS/32R-VSB22U99
|
|
R902535086
|
AA10VSO140LA8DS/32R-VSB32U00E
|
|
R902473174
|
AA10VSO140LA8DS/32R-VSB32UB9
|
|
R902460516
|
AA10VSO140LA9DS/32R-VSB32U99
|
|
R987124871
|
A10VSO140LA6DS/32R-VPB22U99KW30-1450G
|
|
R902490899
|
A10VSO140LA6DG/32R+A10VSO140LA6DG/32RE
|
|
R902515438
|
A10VSO140LA6DS/32R+A10VSO100LA6DS/32R
|
|
R902490865
|
A10VSO140LA6DS/32R+A10VSO18DFR1/31R
|
|
R902491913
|
A10VSO140LA6DS/32R+A10VSO45LA7DS/32R
|
|
R902475114
|
A10VSO140LA7DS/32R+A10VSO100LA7DS/32R
|
|
R902490863
|
A10VSO140LA7DS/32R+A10VSO140LA7DS/32R
|
|
R902492688
|
A10VSO140LA7DS/32R+A10VSO18DFR1/31R
|
|
R902473173
|
A10VSO140LA8DS/32R+A10VSO100LA9DS/32R
|
|
R902479890
|
A4VSO250LR2S/30R+A10VSO140LA6DS/32R
|
|
R902535700
|
A4VSO355LR2N/30R+A10VSO140LA8DS/32R
|
一 The variable displacement axial piston pump type A4VSO in swashplate design is designed for open circuit hydrostatic drives
一 The flow is proportional to the input drive speed and displacement.
一 By adjusting the swashplate., it is possible to infinitely vary the flow.
一 Infinitely variable displacement Slot-controlled swashplate design.
一 Good suction characteristics
一 Permissible nominal operating pressure 350 bar
一 Low noise level,Long service life
一 Drive shaft capable of absorbing axial and radial loads
一 Modular design, Good power/weight ratio
一 Short control times
一 Through drive and pump combinations possible
一 Swash plate angle indicator
一 Optional mounting position
一 Operation on HF fluids under reduced operational,parameter
