BETTER PARTS Machinery Co., Ltd. bbonniee@163.com 86--13535077468
تفاصيل المنتج
Place of Origin: China
اسم العلامة التجارية: REXROTH
إصدار الشهادات: CE ISO 9001
Model Number: A2FM series
شروط الدفع والشحن
Minimum Order Quantity: 1
الأسعار: nigotiation
Packaging Details: Standard Wooden
Delivery Time: 7days
Payment Terms: T/T
Supply Ability: 2000/month
Standard or Nonstandard: |
Standard |
Performance: |
Corrosion Resistance |
Material: |
Cast Iron |
Displacement: |
Standanrd, 10 to 1000 |
Motor Type: |
Piston Motor |
Warranty: |
1 Year |
Condition: |
New |
After-sales Service Provided: |
Online support |
Usage: |
Oil |
Application: |
Other |
Fuel: |
hydraulic oil |
Power: |
Hydraulic |
Pressure: |
High Pressure,Low Pressure |
Weight: |
22-160kg |
Feature: |
High Efficiency |
Name: |
hydraulic axial piston pump |
Standard or Nonstandard: |
Standard |
Performance: |
Corrosion Resistance |
Material: |
Cast Iron |
Displacement: |
Standanrd, 10 to 1000 |
Motor Type: |
Piston Motor |
Warranty: |
1 Year |
Condition: |
New |
After-sales Service Provided: |
Online support |
Usage: |
Oil |
Application: |
Other |
Fuel: |
hydraulic oil |
Power: |
Hydraulic |
Pressure: |
High Pressure,Low Pressure |
Weight: |
22-160kg |
Feature: |
High Efficiency |
Name: |
hydraulic axial piston pump |
BTPS العلامة التجارية المتاحة
Rexroth A2FM 6x Series Piston محرك ثابت
محرك الضغط العالي متعدد الأغراض
الحجم 5 ... 1000
الضغط الاسمي يصل إلى 400 بار
الحد الأقصى للضغط يصل 450 بار
دائرة مفتوحة ومغلقة
نسخة مترية
البيانات الفنية
| مقاس | 5 | 10 | 12 | 16 | 23 | 28 | 32 | 107 | 125 | 160 | 180 | 200 | 250 | 355 | 500 | |||
| النزوح الهندسة ، لكل ثورة |
VG | سم | 4.93 | 10.3 | 12 | 16 | 22.9 | 28.1 | 32 | 106.7 | 125 | 160.4 | 180 | 200 | 250 | 355 | 500 | |
| الضغط الاسمي | pnom | حاجِز | 315 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 350 | 350 | 350 | |
| الحد الأقصى للضغط | PMAX | حاجِز | 350 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 400 | 400 | 400 | |
| السرعة القصوى | nnom 1) | دورة في الدقيقة | 10000 | 8000 | 8000 | 8000 | 6300 | 6300 | 6300 | 4000 | 4000 | 3600 | 3600 | 2750 | 2700 | 2240 | 2000 | |
| NMAX 2) | دورة في الدقيقة | 11000 | 8800 | 8800 | 8800 | 6900 | 6900 | 6900 | 4400 | 4400 | 4000 | 4000 | 3000 | |||||
| تدفق مدخل 3) | في NNOM | QV | ل/دقيقة | 49 | 82 | 96 | 128 | 144 | 177 | 202 | 427 | 500 | 577 | 648 | 550 | 675 | 795 | 1000 |
| عزم الدوران 4) | في PNOM | م | نانومتر | 24.7 | 66 | 76 | 102 | 146 | 179 | 204 | 679 | 796 | 1021 | 1146 | 1273 | 1393 | 1978 | 2785 |
| تصلب دوار | ج | knm/rad | 0.63 | 0.92 | 1.25 | 1.59 | 2.56 | 2.93 | 3.12 | 11.2 | 11.9 | 17.4 | 18.2 | 57.3 | 73.1 | 96.1 | 144 | |
| لحظة الجمود للمجموعة الدوارة | JTW | كجم · م² | 0.00006 | 0.0004 | 0.0004 | 0.0004 | 0.0012 | 0.0012 | 0.0012 | 0.0116 | 0.0116 | 0.022 | 0.022 | 0.0353 | 0.061 | 0.102 | 0.178 | |
| أقصى تسارع زاوي | ɑ | RAD/S² | 5000 | 5000 | 5000 | 5000 | 6500 | 6500 | 6500 | 4500 | 4500 | 3500 | 3500 | 11000 | 10000 | 8300 | 5500 | |
| حجم القضية | الخامس | ل | 0.17 | 0.17 | 0.17 | 0.2 | 0.2 | 0.2 | 0.8 | 0.8 | 1.1 | 1.1 | 2.7 | 2.5 | 3.5 | 4.2 | ||
| الوزن (تقريبا) | م | كجم | 2.5 | 5.4 | 5.4 | 5.4 | 9.5 | 9.5 | 9.5 | 32 | 32 | 45 | 45 | 66 | 73 | 110 | 155 | |
- محرك ثابت مع مجموعة دوارة مكبس محورية مدببة من تصميم محور العازف ، لمحركات الهيدروستاتيكية في دوائر مفتوحة ومغلقة - لاستخدامها في مناطق التطبيق المتنقلة والثابتة - تعتمد سرعة الخرج على تدفق المضخة وإزاحة المحرك. - يزداد عزم الدوران الناتج مع الفرق في الضغط بين الجوانب عالية الضغط والمنخفضة مع زيادة الإزاحة. - اختيار دقيق للإزاحة المقدمة ، تسمح بأحجام التصريح بمطابقة كل تطبيق عمليا
| تعليمات السلامة | |||
| 1 ، تم تصميم محرك A2FM للاستخدام في حلقة مفتوحة. - يجب تنفيذ تخطيط المشروع وتركيب وتكليف وحدة المكبس المحورية من قبل موظفين مؤهلين. ؛ |
|||
| 2 ، قبل استخدام وحدة المكبس المحورية ، يرجى قراءة الدليل المقابل تمامًا. إذا لزم الأمر ، يمكنك الحصول عليها من Rexroth. - أثناء العملية وبعدها بفترة وجيزة ، قد يكون هناك خطر حرق وحدة المكبس المحورية. ؛ |
|||
| 3 ، ينبغي اتخاذ تدابير السلامة المناسبة (مثل ارتداء ملابس واقية). - قد تختلف خصائص وحدة المكبس المحورية مع ظروف عمل مختلفة (ضغط العمل ، درجة حرارة الزيت) لعنصر المكبس المحوري ، قد تتغير الخصائص. |
|||
| منفذ زيت خط أنابيب العمل | |||
| 1 ، تم تصميم فوهات الزيت والخيوط الثابتة لأقصى قدر من الضغط الموصوف. يجب أن يضمن مصنعو الماكينة أو النظام أن عامل أمان مكونات التوصيل والأنابيب يلبي ظروف العمل المحددة (الضغط ، التدفق ، الزيت الهيدروليكي ، درجة الحرارة) ؛ | |||
| 2 ، يتم استخدام فوهات خط أنابيب العمل والفوهات الوظيفية فقط في خطوط الأنابيب الهيدروليكية ؛ | |||
| 3 ، يجب اتباع البيانات والتعليمات الواردة هنا ؛ | |||
|
4 ، لا يمكن الموافقة على المنتج كمكون يتبع مفهوم السلامة الميكانيكية العامة لـ ISO 13849 ؛
|
| A2FM5/60WPB030 | A2FM5/60WPB030J | A2FM5/60WPCB030 | A2FM5/60WPCB030J |
| A2FM5/60WVBB030 | A2FM5/60WVB030J | A2FM5/60WVCB030 | A2FM5/60WVCB030J |
| A2FM10/61WPAB030 | A2FM10/61WPAB030J | A2FM10/61WPZB030 | A2FM10/61WPZB030J |
| A2FM10/61WPBB030 | A2FM10/61WPBB030J | A2FM10/61WPPB030 | A2FM10/61WPPB030J |
| A2FM10/61WVAB030 | A2FM10/61WVAB030J | A2FM10/61WVZB030 | A2FM10/61WVZB030J |
| A2FM10/61WVBB030 | A2FM10/61WVBB030J | A2FM10/61WVPB030 | A2FM10/61WVPB030J |
| A2FM10/61WPAB040 | A2FM10/61WPAB040J | A2FM10/61WPZB040 | A2FM10/61WPZB040J |
| A2FM10/61WPBB040 | A2FM10/61WPBB040J | A2FM10/61WPPB040 | A2FM10/61WPPB040J |
| A2FM10/61WVAB040 | A2FM10/61WVAB040J | A2FM10/61WVZB040 | A2FM10/61WVZB040J |
| A2FM10/61WVBB040 | A2FM10/61WVB040J | A2FM10/61WVPB040 | A2FM10/61WVPB040J |
| A2FM12/61WPAB030 | A2FM12/61WPAB030J | A2FM12/61WPZB030 | A2FM12/61WPZB030J |
| A2FM12/61WPBB030 | A2FM12/61WPBB030J | A2FM12/61WPPB030 | A2FM12/61WPPB030J |
| A2FM12/61WVAB030 | A2FM12/61WVAB030J | A2FM12/61WVZB030 | A2FM12/61WVZB030J |
| A2FM12/61WVBB030 | A2FM12/61WVBB030J | A2FM12/61WVPB030 | A2FM12/61WVPB030J |
| A2FM12/61WPAB040 | A2FM12/61WPAB040J | A2FM12/61WPZB040 | A2FM12/61WPZB040J |
| A2FM12/61WPBB040 | A2FM12/61WPBB040J | A2FM12/61WPPB040 | A2FM12/61WPPB040J |
| A2FM12/61WVAB040 | A2FM12/61WVAB040J | A2FM12/61WVZB040 | A2FM12/61WVZB040J |
| A2FM12/61WVBB040 | A2FM12/61WVBB040J | A2FM12/61WVPB040 | A2FM12/61WVPB040J |
| A2FM16/61WPAB030 | A2FM16/61WPAB030J | A2FM16/61WPZB030 | A2FM16/61WPZB030J |
| A2FM16/61WPBB030 | A2FM16/61WPBB030J | A2FM16/61WPPB030 | A2FM16/61WPPB030J |
| A2FM16/61WVAB030 | A2FM16/61WVAB030J | A2FM16/61WVZB030 | A2FM16/61WVZB030J |
| A2FM16/61WVBB030 | A2FM16/61WVBB030J | A2FM16/61WVPB030 | A2FM16/61WVPB030J |
| A2FM16/61WPAB040 | A2FM16/61WPAB040J | A2FM16/61WPZB040 | A2FM16/61WPZB040J |
| A2FM16/61WPBB040 | A2FM16/61WPBB040J | A2FM16/61WPPB040 | A2FM16/61WPPB040J |
| A2FM16/61WVAB040 | A2FM16/61WVAB040J | A2FM16/61WVZB040 | A2FM16/61WVZB040J |
| A2FM16/61WVB040 | A2FM16/61WVB040J | A2FM16/61WVPB040 | A2FM16/61WVPB040J |
| A2FM23/61WPAB030 | A2FM23/61WPAB030J | A2FM23/61WPZB030 | A2FM23/61WPZB030J |
| A2FM23/61WPBB030 | A2FM23/61WPBB030J | A2FM23/61WPPB030 | A2FM23/61WPPB030J |
| A2FM23/61WVAB030 | A2FM23/61WVAB030J | A2FM23/61WVZB030 | A2FM23/61WVZB030J |
| A2FM23/61WVBB030 | A2FM23/61WVBB030J | A2FM23/61WVPB030 | A2FM23/61WVPB030J |
| A2FM23/61WPAB040 | A2FM23/61WPAB040J | A2FM23/61WPZB040 | A2FM23/61WPZB040J |
| A2FM23/61WPBB040 | A2FM23/61WPBB040J | A2FM23/61WPPB040 | A2FM23/61WPPB040J |
| A2FM23/61WVAB040 | A2FM23/61WVAB040J | A2FM23/61WVZB040 | A2FM23/61WVZB040J |
| A2FM23/61WVB040 | A2FM23/61WVBB040J | A2FM23/61WVPB040 | A2FM23/61WVPB040J |
| A2FM23/61WPAB010 | A2FM23/61WPAB010J | A2FM23/61WPZB010 | A2FM23/61WPZB010J |
| A2FM23/61WPBB010 | A2FM23/61WPBB010J | A2FM23/61WPPB010 | A2FM23/61WPPB010J |
| A2FM23/61WVAB010 | A2FM23/61WVAB010J | A2FM23/61WVZB010 | A2FM23/61WVZB010J |
| A2FM23/61WVBB010 | A2FM23/61WVBB010J | A2FM23/61WVPB010 | A2FM23/61WVPB010J |
| A2FM23/61WPAB020 | A2FM23/61WPAB020J | A2FM23/61WPZB020 | A2FM23/61WPZB020J |
| A2FM23/61WPBB020 | A2FM23/61WPBB020J | A2FM23/61WPPB020 | A2FM23/61WPPB020J |
| A2FM23/61WVAB020 | A2FM23/61WVAB020J | A2FM23/61WVZB020 | A2FM23/61WVZB020J |
| A2FM23/61WVBB020 | A2FM23/61WVBB020J | A2FM23/61WVPB020 | A2FM23/61WVPB020J |
| A2FM28/61WPAB030 | A2FM28/61WPAB030J | A2FM28/61WPZB030 | A2FM28/61WPZB030J |
| A2FM28/61WPBB030 | A2FM28/61WPBB030J | A2FM28/61WPPB030 | A2FM28/61WPPB030J |
| A2FM28/61WVAB030 | A2FM28/61WVAB030J | A2FM28/61WVZB030 | A2FM28/61WVZB030J |
| A2FM28/61WVBB030 | A2FM28/61WVBB030J | A2FM28/61WVPB030 | A2FM28/61WVPB030J |
| A2FM28/61WPAB040 | A2FM28/61WPAB040J | A2FM28/61WPZB040 | A2FM28/61WPZB040J |
| A2FM28/61WPBB040 | A2FM28/61WPBB040J | A2FM28/61WPPB040 | A2FM28/61WPPB040J |
| A2FM28/61WVAB040 | A2FM28/61WVAB040J | A2FM28/61WVZB040 | A2FM28/61WVZB040J |
| A2FM28/61WVBB040 | A2FM28/61WVB040J | A2FM28/61WVPB040 | A2FM28/61WVPB040J |
| A2FM28/61WPAB010 | A2FM28/61WPAB010J | A2FM28/61WPZB010 | A2FM28/61WPZB010J |
| A2FM28/61WPBB010 | A2FM28/61WPBB010J | A2FM28/61WPPB010 | A2FM28/61WPPB010J |
| A2FM28/61WVAB010 | A2FM28/61WVAB010J | A2FM28/61WVZB010 | A2FM28/61WVZB010J |
| A2FM28/61WVBB010 | A2FM28/61WVBB010J | A2FM28/61WVPB010 | A2FM28/61WVPB010J |
| A2FM28/61WPAB020 | A2FM28/61WPAB020J | A2FM28/61WPZB020 | A2FM28/61WPZB020J |
| A2FM28/61WPBB020 | A2FM28/61WPBB020J | A2FM28/61WPPB020 | A2FM28/61WPPB020J |
| A2FM28/61WVAB020 | A2FM28/61WVAB020J | A2FM28/61WVZB020 | A2FM28/61WVZB020J |
| A2FM28/61WVBB020 | A2FM28/61WVBB020J | A2FM28/61WVPB020 | A2FM28/61WVPB020J |
| A2FM28/61WPAB100 | A2FM28/61WPAB100J | A2FM28/61WPZB100 | A2FM28/61WPZB100J |
| A2FM28/61WPBB100 | A2FM28/61WPBB100J | A2FM28/61WPPB100 | A2FM28/61WPPB100J |
| A2FM28/61WVAB100 | A2FM28/61WVAB100J | A2FM28/61WVZB100 | A2FM28/61WVZB100J |
| A2FM28/61WVBB100 | A2FM28/61WVBB100J | A2FM28/61WVPB100 | A2FM28/61WVPB100J |
| A2FM28/61WPAB181 | A2FM28/61WPAB181J | A2FM28/61WPZB181 | A2FM28/61WPZB181J |
| A2FM28/61WPBB181 | A2FM28/61WPBB181J | A2FM28/61WPPB181 | A2FM28/61WPPB181J |
| A2FM28/61WVAB181 | A2FM28/61WVAB181J | A2FM28/61WVZB181 | A2FM28/61WVZB181J |
| A2FM28/61WVBB181 | A2FM28/61WVBB181J | A2FM28/61WVPB181 | A2FM28/61WVPB181J |
| A2FM28/61WPAB191 | A2FM28/61WPAB191J | A2FM28/61WPZB191 | A2FM28/61WPZB191J |
| A2FM28/61WPBB191 | A2FM28/61WPBB191J | A2FM28/61WPPB191 | A2FM28/61WPPB191J |
| A2FM28/61WVAB191 | A2FM28/61WVAB191J | A2FM28/61WVZB191 | A2FM28/61WVZB191J |
| A2FM28/61WVBB191 | A2FM28/61WVBB191J | A2FM28/61WVPB191 | A2FM28/61WVPB191J |
| A2FM28/61WPAB192 | A2FM28/61WPAB192J | A2FM28/61WPZB192 | A2FM28/61WPZB192J |
| A2FM28/61WPBB192 | A2FM28/61WPBB192J | A2FM28/61WPPB192 | A2FM28/61WPPB192J |
| A2FM28/61WVAB192 | A2FM28/61WVAB192J | A2FM28/61WVZB192 | A2FM28/61WVZB192J |
| A2FM28/61WVBB192 | A2FM28/61WVBB192J | A2FM28/61WVPB192 | A2FM28/61WVPB192J |
| A2FM32/61WPAB030 | A2FM32/61WPAB030J | A2FM32/61WPZB030 | A2FM32/61WPZB030J |
| A2FM32/61WPBB030 | A2FM32/61WPBB030J | A2FM32/61WPPB030 | A2FM32/61WPPB030J |
| A2FM32/61WVAB030 | A2FM32/61WVAB030J | A2FM32/61WVZB030 | A2FM32/61WVZB030J |
| A2FM32/61WVBB030 | A2FM32/61WVBB030J | A2FM32/61WVPB030 | A2FM32/61WVPB030J |
| A2FM32/61WPAB040 | A2FM32/61WPAB040J | A2FM32/61WPZB040 | A2FM32/61WPZB040J |
| A2FM32/61WPBB040 | A2FM32/61WPBB040J | A2FM32/61WPPB040 | A2FM32/61WPPB040J |
| A2FM32/61WVAB040 | A2FM32/61WVAB040J | A2FM32/61WVZB040 | A2FM32/61WVZB040J |
| A2FM32/61WVBB040 | A2FM32/61WVB040J | A2FM32/61WVPB040 | A2FM32/61WVPB040J |
| A2FM32/61WPAB010 | A2FM32/61WPAB010J | A2FM32/61WPZB010 | A2FM32/61WPZB010J |
| A2FM32/61WPBB010 | A2FM32/61WPBB010J | A2FM32/61WPPB010 | A2FM32/61WPPB010J |
| A2FM32/61WVAB010 | A2FM32/61WVAB010J | A2FM32/61WVZB010 | A2FM32/61WVZB010J |
| A2FM32/61WVBB010 | A2FM32/61WVBB010J | A2FM32/61WVPB010 | A2FM32/61WVPB010J |
| A2FM32/61WPAB020 | A2FM32/61WPAB020J | A2FM32/61WPZB020 | A2FM32/61WPZB020J |
| A2FM32/61WPBB020 | A2FM32/61WPBB020J | A2FM32/61WPPB020 | A2FM32/61WPPB020J |
| A2FM32/61WVAB020 | A2FM32/61WVAB020J | A2FM32/61WVZB020 | A2FM32/61WVZB020J |
| A2FM32/61WVBB020 | A2FM32/61WVBB020J | A2FM32/61WVPB020 | A2FM32/61WVPB020J |
| A2FM32/61WPAB100 | A2FM32/61WPAB100J | A2FM32/61WPZB100 | A2FM32/61WPZB100J |
| A2FM32/61WPBB100 | A2FM32/61WPBB100J | A2FM32/61WPPB100 | A2FM32/61WPPB100J |
| A2FM32/61WVAB100 | A2FM32/61WVAB100J | A2FM32/61WVZB100 | A2FM32/61WVZB100J |
| A2FM32/61WVBB100 | A2FM32/61WVBB100J | A2FM32/61WVPB100 | A2FM32/61WVPB100J |
| A2FM32/61WPAB181 | A2FM32/61WPAB181J | A2FM32/61WPZB181 | A2FM32/61WPZB181J |
| A2FM32/61WPBB181 | A2FM32/61WPBB181J | A2FM32/61WPPB181 | A2FM32/61WPPB181J |
| A2FM32/61WVAB181 | A2FM32/61WVAB181J | A2FM32/61WVZB181 | A2FM32/61WVZB181J |
| A2FM32/61WVBB181 | A2FM32/61WVBB181J | A2FM32/61WVPB181 | A2FM32/61WVPB181J |
| A2FM32/61WPAB191 | A2FM32/61WPAB191J | A2FM32/61WPZB191 | A2FM32/61WPZB191J |
| A2FM32/61WPBB191 | A2FM32/61WPBB191J | A2FM32/61WPPB191 | A2FM32/61WPPB191J |
| A2FM32/61WVAB191 | A2FM32/61WVAB191J | A2FM32/61WVZB191 | A2FM32/61WVZB191J |
| A2FM32/61WVBB191 | A2FM32/61WVBB191J | A2FM32/61WVPB191 | A2FM32/61WVPB191J |
| A2FM32/61WPAB192 | A2FM32/61WPAB192J | A2FM32/61WPZB192 | A2FM32/61WPZB192J |
| A2FM32/61WPBB192 | A2FM32/61WPBB192J | A2FM32/61WPPB192 | A2FM32/61WPPB192J |
| A2FM32/61WVAB192 | A2FM32/61WVAB192J | A2FM32/61WVZB192 | A2FM32/61WVZB192J |
| A2FM32/61WVBB192 | A2FM32/61WVBB192J | A2FM32/61WVPB192 | A2FM32/61WVPB192J |
| A2FM45/61WPAB027 | A2FM45/61WPAB027J | A2FM45/61WPZB027 | A2FM45/61WPZB027J |
| A2FM45/61WPBB027 | A2FM45/61WPBB027J | A2FM45/61WPPB027 | A2FM45/61WPPB027J |
| A2FM45/61WVAB027 | A2FM45/61WVAB027J | A2FM45/61WVZB027 | A2FM45/61WVZB027J |
| A2FM45/61WVBB027 | A2FM45/61WVB027J | A2FM45/61WVPB027 | A2FM45/61WVPB027J |
| A2FM45/61WPAB040 | A2FM45/61WPAB040J | A2FM45/61WPZB040 | A2FM45/61WPZB040J |
| A2FM45/61WPBB040 | A2FM45/61WPBB040J | A2FM45/61WPPB040 | A2FM45/61WPPB040J |
| A2FM45/61WVAB040 | A2FM45/61WVAB040J | A2FM45/61WVZB040 | A2FM45/61WVZB040J |
| A2FM45/61WVB040 | A2FM45/61WVBB040J | A2FM45/61WVPB040 | A2FM45/61WVPB040J |
| A2FM45/61WPAB010 | A2FM45/61WPAB010J | A2FM45/61WPZB010 | A2FM45/61WPZB010J |
| A2FM45/61WPBB010 | A2FM45/61WPBB010J | A2FM45/61WPPB010 | A2FM45/61WPPB010J |
| A2FM45/61WVAB010 | A2FM45/61WVAB010J | A2FM45/61WVZB010 | A2FM45/61WVZB010J |
| A2FM45/61WVBB010 | A2FM45/61WVBB010J | A2FM45/61WVPB010 | A2FM45/61WVPB010J |
| A2FM45/61WPAB020 | A2FM45/61WPAB020J | A2FM45/61WPZB020 | A2FM45/61WPZB020J |
| A2FM45/61WPBB020 | A2FM45/61WPBB020J | A2FM45/61WPPB020 | A2FM45/61WPPB020J |
| A2FM45/61WVAB020 | A2FM45/61WVAB020J | A2FM45/61WVZB020 | A2FM45/61WVZB020J |
| A2FM45/61WVBB020 | A2FM45/61WVBB020J | A2FM45/61WVPB020 | A2FM45/61WVPB020J |
| A2FM45/61WPAB100 | A2FM45/61WPAB100J | A2FM45/61WPZB100 | A2FM45/61WPZB100J |
| A2FM45/61WPBB100 | A2FM45/61WPBB100J | A2FM45/61WPPB100 | A2FM45/61WPPB100J |
| A2FM45/61WVAB100 | A2FM45/61WVAB100J | A2FM45/61WVZB100 | A2FM45/61WVZB100J |
| A2FM45/61WVBB100 | A2FM45/61WVBB100J | A2FM45/61WVPB100 | A2FM45/61WVPB100J |
| A2FM45/61WPAB181 | A2FM45/61WPAB181J | A2FM45/61WPZB181 | A2FM45/61WPZB181J |
| A2FM45/61WPBB181 | A2FM45/61WPBB181J | A2FM45/61WPPB181 | A2FM45/61WPPB181J |
| A2FM45/61WVAB181 | A2FM45/61WVAB181J | A2FM45/61WVZB181 | A2FM45/61WVZB181J |
| A2FM45/61WVBB181 | A2FM45/61WVBB181J | A2FM45/61WVPB181 | A2FM45/61WVPB181J |
| A2FM45/61WPAB191 | A2FM45/61WPAB191J | A2FM45/61WPZB191 | A2FM45/61WPZB191J |
| A2FM45/61WPBB191 | A2FM45/61WPBB191J | A2FM45/61WPPB191 | A2FM45/61WPPB191J |
| A2FM45/61WVAB191 | A2FM45/61WVAB191J | A2FM45/61WVZB191 | A2FM45/61WVZB191J |
| A2FM45/61WVBB191 | A2FM45/61WVBB191J | A2FM45/61WVPB191 | A2FM45/61WVPB191J |
| A2FM45/61WPAB192 | A2FM45/61WPAB192J | A2FM45/61WPZB192 | A2FM45/61WPZB192J |
| A2FM45/61WPBB192 | A2FM45/61WPBB192J | A2FM45/61WPPB192 | A2FM45/61WPPB192J |
| A2FM45/61WVAB192 | A2FM45/61WVAB192J | A2FM45/61WVZB192 | A2FM45/61WVZB192J |
| A2FM45/61WVBB192 | A2FM45/61WVBB192J | A2FM45/61WVPB192 | A2FM45/61WVPB192J |
| A2FM56/61WPAB029 | A2FM56/61WPAB029J | A2FM56/61WPZB029 | A2FM56/61WPZB029J |
| A2FM56/61WPBB029 | A2FM56/61WPBB029J | A2FM56/61WPPB029 | A2FM56/61WPPB029J |
| A2FM56/61WVAB029 | A2FM56/61WVAB029J | A2FM56/61WVZB029 | A2FM56/61WVZB029J |
| A2FM56/61WVBB029 | A2FM56/61WVB029J | A2FM56/61WVPB029 | A2FM56/61WVPB029J |
| A2FM56/61WPAB040 | A2FM56/61WPAB040J | A2FM56/61WPZB040 | A2FM56/61WPZB040J |
| A2FM56/61WPBB040 | A2FM56/61WPBB040J | A2FM56/61WPPB040 | A2FM56/61WPPB040J |
| A2FM56/61WVAB040 | A2FM56/61WVAB040J | A2FM56/61WVZB040 | A2FM56/61WVZB040J |
| A2FM56/61WVBB040 | A2FM56/61WVBB040J | A2FM56/61WVPB040 | A2FM56/61WVPB040J |
| A2FM56/61WPAB010 | A2FM56/61WPAB010J | A2FM56/61WPZB010 | A2FM56/61WPZB010J |
| A2FM56/61WPBB010 | A2FM56/61WPBB010J | A2FM56/61WPPB010 | A2FM56/61WPPB010J |
| A2FM56/61WVAB010 | A2FM56/61WVAB010J | A2FM56/61WVZB010 | A2FM56/61WVZB010J |
| A2FM56/61WVBB010 | A2FM56/61WVBB010J | A2FM56/61WVPB010 | A2FM56/61WVPB010J |
| A2FM56/61WPAB020 | A2FM56/61WPAB020J | A2FM56/61WPZB020 | A2FM56/61WPZB020J |
| A2FM56/61WPBB020 | A2FM56/61WPBB020J | A2FM56/61WPPB020 | A2FM56/61WPPB020J |
| A2FM56/61WVAB020 | A2FM56/61WVAB020J | A2FM56/61WVZB020 | A2FM56/61WVZB020J |
| A2FM56/61WVBB020 | A2FM56/61WVBB020J | A2FM56/61WVPB020 | A2FM56/61WVPB020J |
| A2FM56/61WPAB100 | A2FM56/61WPAB100J | A2FM56/61WPZB100 | A2FM56/61WPZB100J |
| A2FM56/61WPBB100 | A2FM56/61WPBB100J | A2FM56/61WPPB100 | A2FM56/61WPPB100J |
| A2FM56/61WVAB100 | A2FM56/61WVAB100J | A2FM56/61WVZB100 | A2FM56/61WVZB100J |
| A2FM56/61WVBB100 | A2FM56/61WVBB100J | A2FM56/61WVPB100 | A2FM56/61WVPB100J |
| A2FM56/61WPAB181 | A2FM56/61WPAB181J | A2FM56/61WPZB181 | A2FM56/61WPZB181J |
| A2FM56/61WPBB181 | A2FM56/61WPBB181J | A2FM56/61WPPB181 | A2FM56/61WPPB181J |
| A2FM56/61WVAB181 | A2FM56/61WVAB181J | A2FM56/61WVZB181 | A2FM56/61WVZB181J |
| A2FM56/61WVBB181 | A2FM56/61WVBB181J | A2FM56/61WVPB181 | A2FM56/61WVPB181J |
| A2FM56/61WPAB191 | A2FM56/61WPAB191J | A2FM56/61WPZB191 | A2FM56/61WPZB191J |
| A2FM56/61WPBB191 | A2FM56/61WPBB191J | A2FM56/61WPPB191 | A2FM56/61WPPB191J |
| A2FM56/61WVAB191 | A2FM56/61WVAB191J | A2FM56/61WVZB191 | A2FM56/61WVZB191J |
| A2FM56/61WVBB191 | A2FM56/61WVBB191J | A2FM56/61WVPB191 | A2FM56/61WVPB191J |
| A2FM56/61WPAB192 | A2FM56/61WPAB192J | A2FM56/61WPZB192 | A2FM56/61WPZB192J |
| A2FM56/61WPBB192 | A2FM56/61WPBB192J | A2FM56/61WPPB192 | A2FM56/61WPPB192J |
| A2FM56/61WVAB192 | A2FM56/61WVAB192J | A2FM56/61WVZB192 | A2FM56/61WVZB192J |
| A2FM56/61WVBB192 | A2FM56/61WVBB192J | A2FM56/61WVPB192 | A2FM56/61WVPB192J |
| A2FM63/61WPAB029 | A2FM63/61WPAB029J | A2FM63/61WPZB029 | A2FM63/61WPZB029J |
| A2FM63/61WPBB029 | A2FM63/61WPBB029J | A2FM63/61WPPB029 | A2FM63/61WPPB029J |
| A2FM63/61WVAB029 | A2FM63/61WVAB029J | A2FM63/61WVZB029 | A2FM63/61WVZB029J |
| A2FM63/61WVBB029 | A2FM63/61WVB029J | A2FM63/61WVPB029 | A2FM63/61WVPB029J |
| A2FM63/61WPAB040 | A2FM63/61WPAB040J | A2FM63/61WPZB040 | A2FM63/61WPZB040J |
| A2FM63/61WPBB040 | A2FM63/61WPBB040J | A2FM63/61WPPB040 | A2FM63/61WPPB040J |
| A2FM63/61WVAB040 | A2FM63/61WVAB040J | A2FM63/61WVZB040 | A2FM63/61WVZB040J |
| A2FM63/61WVBB040 | A2FM63/61WVBB040J | A2FM63/61WVPB040 | A2FM63/61WVPB040J |
| A2FM63/61WPAB010 | A2FM63/61WPAB010J | A2FM63/61WPZB010 | A2FM63/61WPZB010J |
| A2FM63/61WPBB010 | A2FM63/61WPBB010J | A2FM63/61WPPB010 | A2FM63/61WPPB010J |
| A2FM63/61WVAB010 | A2FM63/61WVAB010J | A2FM63/61WVZB010 | A2FM63/61WVZB010J |
| A2FM63/61WVBB010 | A2FM63/61WVBB010J | A2FM63/61WVPB010 | A2FM63/61WVPB010J |
| A2FM63/61WPAB020 | A2FM63/61WPAB020J | A2FM63/61WPZB020 | A2FM63/61WPZB020J |
| A2FM63/61WPBB020 | A2FM63/61WPBB020J | A2FM63/61WPPB020 | A2FM63/61WPPB020J |
| A2FM63/61WVAB020 | A2FM63/61WVAB020J | A2FM63/61WVZB020 | A2FM63/61WVZB020J |
| A2FM63/61WVBB020 | A2FM63/61WVBB020J | A2FM63/61WVPB020 | A2FM63/61WVPB020J |
| A2FM63/61WPAB100 | A2FM63/61WPAB100J | A2FM63/61WPZB100 | A2FM63/61WPZB100J |
| A2FM63/61WPBB100 | A2FM63/61WPBB100J | A2FM63/61WPPB100 | A2FM63/61WPPB100J |
| A2FM63/61WVAB100 | A2FM63/61WVAB100J | A2FM63/61WVZB100 | A2FM63/61WVZB100J |
| A2FM63/61WVBB100 | A2FM63/61WVBB100J | A2FM63/61WVPB100 | A2FM63/61WVPB100J |
| A2FM63/61WPAB181 | A2FM63/61WPAB181J | A2FM63/61WPZB181 | A2FM63/61WPZB181J |
| A2FM63/61WPBB181 | A2FM63/61WPBB181J | A2FM63/61WPPB181 | A2FM63/61WPPB181J |
| A2FM63/61WVAB181 | A2FM63/61WVAB181J | A2FM63/61WVZB181 | A2FM63/61WVZB181J |
| A2FM63/61WVBB181 | A2FM63/61WVBB181J | A2FM63/61WVPB181 | A2FM63/61WVPB181J |
| A2FM63/61WPAB191 | A2FM63/61WPAB191J | A2FM63/61WPZB191 | A2FM63/61WPZB191J |
| A2FM63/61WPBB191 | A2FM63/61WPBB191J | A2FM63/61WPPB191 | A2FM63/61WPPB191J |
| A2FM63/61WVAB191 | A2FM63/61WVAB191J | A2FM63/61WVZB191 | A2FM63/61WVZB191J |
| A2FM63/61WVBB191 | A2FM63/61WVBB191J | A2FM63/61WVPB191 | A2FM63/61WVPB191J |
| A2FM63/61WPAB192 | A2FM63/61WPAB192J | A2FM63/61WPZB192 | A2FM63/61WPZB192J |
| A2FM63/61WPBB192 | A2FM63/61WPBB192J | A2FM63/61WPPB192 | A2FM63/61WPPB192J |
| A2FM63/61WVAB192 | A2FM63/61WVAB192J | A2FM63/61WVZB192 | A2FM63/61WVZB192J |
| A2FM63/61WVBB192 | A2FM63/61WVBB192J | A2FM63/61WVPB192 | A2FM63/61WVPB192J |
| A2FM80/61WPAB029 | A2FM80/61WPAB029J | A2FM80/61WPZB029 | A2FM80/61WPZB029J |
| A2FM80/61WPBB029 | A2FM80/61WPBB029J | A2FM80/61WPPB029 | A2FM80/61WPPB029J |
| A2FM80/61WVAB029 | A2FM80/61WVAB029J | A2FM80/61WVZB029 | A2FM80/61WVZB029J |
| A2FM80/61WVBB029 | A2FM80/61WVB029J | A2FM80/61WVPB029 | A2FM80/61WVPB029J |
| A2FM80/61WPAB010 | A2FM80/61WPAB010J | A2FM80/61WPZB010 | A2FM80/61WPZB010J |
| A2FM80/61WPBB010 | A2FM80/61WPBB010J | A2FM80/61WPPB010 | A2FM80/61WPPB010J |
| A2FM80/61WVAB010 | A2FM80/61WVAB010J | A2FM80/61WVZB010 | A2FM80/61WVZB010J |
| A2FM80/61WVBB010 | A2FM80/61WVBB010J | A2FM80/61WVPB010 | A2FM80/61WVPB010J |
| A2FM80/61WPAB020 | A2FM80/61WPAB020J | A2FM80/61WPZB020 | A2FM80/61WPZB020J |
| A2FM80/61WPBB020 | A2FM80/61WPBB020J | A2FM80/61WPPB020 | A2FM80/61WPPB020J |
| A2FM80/61WVAB020 | A2FM80/61WVAB020J | A2FM80/61WVZB020 | A2FM80/61WVZB020J |
| A2FM80/61WVBB020 | A2FM80/61WVBB020J | A2FM80/61WVPB020 | A2FM80/61WVPB020J |
| A2FM80/61WPAB100 | A2FM80/61WPAB100J | A2FM80/61WPZB100 | A2FM80/61WPZB100J |
| A2FM80/61WPBB100 | A2FM80/61WPBB100J | A2FM80/61WPPB100 | A2FM80/61WPPB100J |
| A2FM80/61WVAB100 | A2FM80/61WVAB100J | A2FM80/61WVZB100 | A2FM80/61WVZB100J |
| A2FM80/61WVBB100 | A2FM80/61WVBB100J | A2FM80/61WVPB100 | A2FM80/61WVPB100J |
| A2FM80/61WPAB181 | A2FM80/61WPAB181J | A2FM80/61WPZB181 | A2FM80/61WPZB181J |
| A2FM80/61WPBB181 | A2FM80/61WPBB181J | A2FM80/61WPPB181 | A2FM80/61WPPB181J |
| A2FM80/61WVAB181 | A2FM80/61WVAB181J | A2FM80/61WVZB181 | A2FM80/61WVZB181J |
| A2FM80/61WVBB181 | A2FM80/61WVBB181J | A2FM80/61WVPB181 | A2FM80/61WVPB181J |
| A2FM80/61WPAB191 | A2FM80/61WPAB191J | A2FM80/61WPZB191 | A2FM80/61WPZB191J |
| A2FM80/61WPBB191 | A2FM80/61WPBB191J | A2FM80/61WPPB191 | A2FM80/61WPPB191J |
| A2FM80/61WVAB191 | A2FM80/61WVAB191J | A2FM80/61WVZB191 | A2FM80/61WVZB191J |
| A2FM80/61WVBB191 | A2FM80/61WVBB191J | A2FM80/61WVPB191 | A2FM80/61WVPB191J |
| A2FM80/61WPAB192 | A2FM80/61WPAB192J | A2FM80/61WPZB192 | A2FM80/61WPZB192J |
| A2FM80/61WPBB192 | A2FM80/61WPBB192J | A2FM80/61WPPB192 | A2FM80/61WPPB192J |
| A2FM80/61WVAB192 | A2FM80/61WVAB192J | A2FM80/61WVZB192 | A2FM80/61WVZB192J |
| A2FM80/61WVBB192 | A2FM80/61WVBB192J | A2FM80/61WVPB192 | A2FM80/61WVPB192J |
| A2FM90/61WPAB029 | A2FM90/61WPAB029J | A2FM90/61WPZB029 | A2FM90/61WPZB029J |
| A2FM90/61WPBB029 | A2FM90/61WPBB029J | A2FM90/61WPPB029 | A2FM90/61WPPB029J |
| A2FM90/61WVAB029 | A2FM90/61WVAB029J | A2FM90/61WVZB029 | A2FM90/61WVZB029J |
| A2FM90/61WVBB029 | A2FM90/61WVB029J | A2FM90/61WVPB029 | A2FM90/61WVPB029J |
| A2FM90/61WPAB010 | A2FM90/61WPAB010J | A2FM90/61WPZB010 | A2FM90/61WPZB010J |
| A2FM90/61WPBB010 | A2FM90/61WPBB010J | A2FM90/61WPPB010 | A2FM90/61WPPB010J |
| A2FM90/61WVAB010 | A2FM90/61WVAB010J | A2FM90/61WVZB010 | A2FM90/61WVZB010J |
| A2FM90/61WVBB010 | A2FM90/61WVBB010J | A2FM90/61WVPB010 | A2FM90/61WVPB010J |
| A2FM90/61WPAB020 | A2FM90/61WPAB020J | A2FM90/61WPZB020 | A2FM90/61WPZB020J |
| A2FM90/61WPBB020 | A2FM90/61WPBB020J | A2FM90/61WPPB020 | A2FM90/61WPPB020J |
| A2FM90/61WVAB020 | A2FM90/61WVAB020J | A2FM90/61WVZB020 | A2FM90/61WVZB020J |
| A2FM90/61WVBB020 | A2FM90/61WVBB020J | A2FM90/61WVPB020 | A2FM90/61WVPB020J |
| A2FM90/61WPAB100 | A2FM90/61WPAB100J | A2FM90/61WPZB100 | A2FM90/61WPZB100J |
| A2FM90/61WPBB100 | A2FM90/61WPBB100J | A2FM90/61WPPB100 | A2FM90/61WPPB100J |
| A2FM90/61WVAB100 | A2FM90/61WVAB100J | A2FM90/61WVZB100 | A2FM90/61WVZB100J |
| A2FM90/61WVBB100 | A2FM90/61WVBB100J | A2FM90/61WVPB100 | A2FM90/61WVPB100J |
| A2FM90/61WPAB181 | A2FM90/61WPAB181J | A2FM90/61WPZB181 | A2FM90/61WPZB181J |
| A2FM90/61WPBB181 | A2FM90/61WPBB181J | A2FM90/61WPPB181 | A2FM90/61WPPB181J |
| A2FM90/61WVAB181 | A2FM90/61WVAB181J | A2FM90/61WVZB181 | A2FM90/61WVZB181J |
| A2FM90/61WVBB181 | A2FM90/61WVBB181J | A2FM90/61WVPB181 | A2FM90/61WVPB181J |
| A2FM90/61WPAB191 | A2FM90/61WPAB191J | A2FM90/61WPZB191 | A2FM90/61WPZB191J |
| A2FM90/61WPBB191 | A2FM90/61WPBB191J | A2FM90/61WPPB191 | A2FM90/61WPPB191J |
| A2FM90/61WVAB191 | A2FM90/61WVAB191J | A2FM90/61WVZB191 | A2FM90/61WVZB191J |
| A2FM90/61WVBB191 | A2FM90/61WVBB191J | A2FM90/61WVPB191 | A2FM90/61WVPB191J |
| A2FM90/61WPAB192 | A2FM90/61WPAB192J | A2FM90/61WPZB192 | A2FM90/61WPZB192J |
| A2FM90/61WPBB192 | A2FM90/61WPBB192J | A2FM90/61WPPB192 | A2FM90/61WPPB192J |
| A2FM90/61WVAB192 | A2FM90/61WVAB192J | A2FM90/61WVZB192 | A2FM90/61WVZB192J |
| A2FM90/61WVBB192 | A2FM90/61WVBB192J | A2FM90/61WVPB192 | A2FM90/61WVPB192J |
| A2FM107/61WPAB191 | A2FM107/61WPAB191J | A2FM107/61WPZB191 | A2FM107/61WPZB191J |
| A2FM107/61WPBB191 | A2FM107/61WPBB191J | A2FM107/61WPPB191 | A2FM107/61WPPB191J |
| A2FM107/61WVAB191 | A2FM107/61WVAB191J | A2FM107/61WVZB191 | A2FM107/61WVZB191J |
| A2FM107/61WVBB191 | A2FM107/61WVBB191J | A2FM107/61WVPB191 | A2FM107/61WVPB191J |
| A2FM107/61WPAB192 | A2FM107/61WPAB192J | A2FM107/61WPZB192 | A2FM107/61WPZB192J |
| A2FM107/61WPBB192 | A2FM107/61WPBB192J | A2FM107/61WPPB192 | A2FM107/61WPPB192J |
| A2FM107/61WVAB192 | A2FM107/61WVAB192J | A2FM107/61WVZB192 | A2FM107/61WVZB192J |
| A2FM107/61WVBB192 | A2FM107/61WVBB192J | A2FM107/61WVPB192 | A2FM107/61WVPB192J |
| A2FM107/61WPAB171 | A2FM107/61WPAB171J | A2FM107/61WPZB171 | A2FM107/61WPZB171J |
| A2FM107/61WPBB171 | A2FM107/61WPBB171J | A2FM107/61WPPB171 | A2FM107/61WPPB171J |
| A2FM107/61WVAB171 | A2FM107/61WVAB171J | A2FM107/61WVZB171 | A2FM107/61WVZB171J |
| A2FM107/61WVBB171 | A2FM107/61WVBB171J | A2FM107/61WVPB171 | A2FM107/61WVPB171J |
| A2FM107/61WPAB178 | A2FM107/61WPAB178J | A2FM107/61WPZB178 | A2FM107/61WPZB178J |
| A2FM107/61WPBB178 | A2FM107/61WPBB178J | A2FM107/61WPPB178 | A2FM107/61WPPB178J |
| A2FM107/61WVAB178 | A2FM107/61WVAB178J | A2FM107/61WVZB178 | A2FM107/61WVZB178J |
| A2FM107/61WVBB178 | A2FM107/61WVBB178J | A2FM107/61WVPB178 | A2FM107/61WVPB178J |
| A2FM107/61WPAB188 | A2FM107/61WPAB188J | A2FM107/61WPZB188 | A2FM107/61WPZB188J |
| A2FM107/61WPBB188 | A2FM107/61WPBB188J | A2FM107/61WPPB188 | A2FM107/61WPPB188J |
| A2FM107/61WVAB188 | A2FM107/61WVAB188J | A2FM107/61WVZB188 | A2FM107/61WVZB188J |
| A2FM107/61WVBB188 | A2FM107/61WVBB188J | A2FM107/61WVPB188 | A2FM107/61WVPB188J |
| A2FM125/61WPAB027 | A2FM125/61WPAB027J | A2FM125/61WPZB027 | A2FM125/61WPZB027J |
| A2FM125/61WPBB027 | A2FM125/61WPBB027J | A2FM125/61WPPB027 | A2FM125/61WPPB027J |
| A2FM125/61WVAB027 | A2FM125/61WVAB027J | A2FM125/61WVZB027 | A2FM125/61WVZB027J |
| A2FM125/61WVBB027 | A2FM125/61WVBB027J | A2FM125/61WVPB027 | A2FM125/61WVPB027J |
| A2FM125/61WPAB010 | A2FM125/61WPAB010J | A2FM125/61WPZB010 | A2FM125/61WPZB010J |
| A2FM125/61WPBB010 | A2FM125/61WPBB010J | A2FM125/61WPPB010 | A2FM125/61WPPB010J |
| A2FM125/61WVAB010 | A2FM125/61WVAB010J | A2FM125/61WVZB010 | A2FM125/61WVZB010J |
| A2FM125/61WVBB010 | A2FM125/61WVBB010J | A2FM125/61WVPB010 | A2FM125/61WVPB010J |
| A2FM125/61WPAB020 | A2FM125/61WPAB020J | A2FM125/61WPZB020 | A2FM125/61WPZB020J |
| A2FM125/61WPBB020 | A2FM125/61WPBB020J | A2FM125/61WPPB020 | A2FM125/61WPPB020J |
| A2FM125/61WVAB020 | A2FM125/61WVAB020J | A2FM125/61WVZB020 | A2FM125/61WVZB020J |
| A2FM125/61WVBB020 | A2FM125/61WVBB020J | A2FM125/61WVPB020 | A2FM125/61WVPB020J |
| A2FM125/61WPAB100 | A2FM125/61WPAB100J | A2FM125/61WPZB100 | A2FM125/61WPZB100J |
| A2FM125/61WPBB100 | A2FM125/61WPBB100J | A2FM125/61WPPB100 | A2FM125/61WPPB100J |
| A2FM125/61WVAB100 | A2FM125/61WVAB100J | A2FM125/61WVZB100 | A2FM125/61WVZB100J |
| A2FM125/61WVBB100 | A2FM125/61WVBB100J | A2FM125/61WVPB100 | A2FM125/61WVPB100J |
| A2FM125/61WPAB181 | A2FM125/61WPAB181J | A2FM125/61WPZB181 | A2FM125/61WPZB181J |
| A2FM125/61WPBB181 | A2FM125/61WPBB181J | A2FM125/61WPPB181 | A2FM125/61WPPB181J |
| A2FM125/61WVAB181 | A2FM125/61WVAB181J | A2FM125/61WVZB181 | A2FM125/61WVZB181J |
| A2FM125/61WVBB181 | A2FM125/61WVBB181J | A2FM125/61WVPB181 | A2FM125/61WVPB181J |
| A2FM125/61WPAB191 | A2FM125/61WPAB191J | A2FM125/61WPZB191 | A2FM125/61WPZB191J |
| A2FM125/61WPBB191 | A2FM125/61WPBB191J | A2FM125/61WPPB191 | A2FM125/61WPPB191J |
| A2FM125/61WVAB191 | A2FM125/61WVAB191J | A2FM125/61WVZB191 | A2FM125/61WVZB191J |
| A2FM125/61WVBB191 | A2FM125/61WVBB191J | A2FM125/61WVPB191 | A2FM125/61WVPB191J |
| A2FM125/61WPAB192 | A2FM125/61WPAB192J | A2FM125/61WPZB192 | A2FM125/61WPZB192J |
| A2FM125/61WPBB192 | A2FM125/61WPBB192J | A2FM125/61WPPB192 | A2FM125/61WPPB192J |
| A2FM125/61WVAB192 | A2FM125/61WVAB192J | A2FM125/61WVZB192 | A2FM125/61WVZB192J |
| A2FM125/61WVBB192 | A2FM125/61WVBB192J | A2FM125/61WVPB192 | A2FM125/61WVPB192J |
| A2FM125/61WPAB171 | A2FM125/61WPAB171J | A2FM125/61WPZB171 | A2FM125/61WPZB171J |
| A2FM125/61WPBB171 | A2FM125/61WPBB171J | A2FM125/61WPPB171 | A2FM125/61WPPB171J |
| A2FM125/61WVAB171 | A2FM125/61WVAB171J | A2FM125/61WVZB171 | A2FM125/61WVZB171J |
| A2FM125/61WVBB171 | A2FM125/61WVBB171J | A2FM125/61WVPB171 | A2FM125/61WVPB171J |
| A2FM125/61WPAB178 | A2FM125/61WPAB178J | A2FM125/61WPZB178 | A2FM125/61WPZB178J |
| A2FM125/61WPBB178 | A2FM125/61WPBB178J | A2FM125/61WPPB178 | A2FM125/61WPPB178J |
| A2FM125/61WVAB178 | A2FM125/61WVAB178J | A2FM125/61WVZB178 | A2FM125/61WVZB178J |
| A2FM125/61WVBB178 | A2FM125/61WVBB178J | A2FM125/61WVPB178 | A2FM125/61WVPB178J |
| A2FM125/61WPAB188 | A2FM125/61WPAB188J | A2FM125/61WPZB188 | A2FM125/61WPZB188J |
| A2FM125/61WPBB188 | A2FM125/61WPBB188J | A2FM125/61WPPB188 | A2FM125/61WPPB188J |
| A2FM125/61WVAB188 | A2FM125/61WVAB188J | A2FM125/61WVZB188 | A2FM125/61WVZB188J |
| A2FM125/61WVBB188 | A2FM125/61WVBB188J | A2FM125/61WVPB188 | A2FM125/61WVPB188J |
| A2FM160/61WPAB027 | A2FM160/61WPAB027J | A2FM160/61WPZB027 | A2FM160/61WPZB027J |
| A2FM160/61WPBB027 | A2FM160/61WPBB027J | A2FM160/61WPPB027 | A2FM160/61WPPB027J |
| A2FM160/61WVAB027 | A2FM160/61WVAB027J | A2FM160/61WVZB027 | A2FM160/61WVZB027J |
| A2FM160/61WVBB027 | A2FM160/61WVBB027J | A2FM160/61WVPB027 | A2FM160/61WVPB027J |
| A2FM160/61WPAB010 | A2FM160/61WPAB010J | A2FM160/61WPZB010 | A2FM160/61WPZB010J |
| A2FM160/61WPBB010 | A2FM160/61WPBB010J | A2FM160/61WPPB010 | A2FM160/61WPPB010J |
| A2FM160/61WVAB010 | A2FM160/61WVAB010J | A2FM160/61WVZB010 | A2FM160/61WVZB010J |
| A2FM160/61WVBB010 | A2FM160/61WVBB010J | A2FM160/61WVPB010 | A2FM160/61WVPB010J |
| A2FM160/61WPAB020 | A2FM160/61WPAB020J | A2FM160/61WPZB020 | A2FM160/61WPZB020J |
| A2FM160/61WPBB020 | A2FM160/61WPBB020J | A2FM160/61WPPB020 | A2FM160/61WPPB020J |
| A2FM160/61WVAB020 | A2FM160/61WVAB020J | A2FM160/61WVZB020 | A2FM160/61WVZB020J |
| A2FM160/61WVBB020 | A2FM160/61WVBB020J | A2FM160/61WVPB020 | A2FM160/61WVPB020J |
| A2FM160/61WPAB100 | A2FM160/61WPAB100J | A2FM160/61WPZB100 | A2FM160/61WPZB100J |
| A2FM160/61WPBB100 | A2FM160/61WPBB100J | A2FM160/61WPPB100 | A2FM160/61WPPB100J |
| A2FM160/61WVAB100 | A2FM160/61WVAB100J | A2FM160/61WVZB100 | A2FM160/61WVZB100J |
| A2FM160/61WVBB100 | A2FM160/61WVBB100J | A2FM160/61WVPB100 | A2FM160/61WVPB100J |
| A2FM160/61WPAB181 | A2FM160/61WPAB181J | A2FM160/61WPZB181 | A2FM160/61WPZB181J |
| A2FM160/61WPBB181 | A2FM160/61WPBB181J | A2FM160/61WPPB181 | A2FM160/61WPPB181J |
| A2FM160/61WVAB181 | A2FM160/61WVAB181J | A2FM160/61WVZB181 | A2FM160/61WVZB181J |
| A2FM160/61WVBB181 | A2FM160/61WVBB181J | A2FM160/61WVPB181 | A2FM160/61WVPB181J |
| A2FM160/61WPAB191 | A2FM160/61WPAB191J | A2FM160/61WPZB191 | A2FM160/61WPZB191J |
| A2FM160/61WPBB191 | A2FM160/61WPBB191J | A2FM160/61WPPB191 | A2FM160/61WPPB191J |
| A2FM160/61WVAB191 | A2FM160/61WVAB191J | A2FM160/61WVZB191 | A2FM160/61WVZB191J |
| A2FM160/61WVBB191 | A2FM160/61WVBB191J | A2FM160/61WVPB191 | A2FM160/61WVPB191J |
| A2FM160/61WPAB192 | A2FM160/61WPAB192J | A2FM160/61WPZB192 | A2FM160/61WPZB192J |
| A2FM160/61WPBB192 | A2FM160/61WPBB192J | A2FM160/61WPPB192 | A2FM160/61WPPB192J |
| A2FM160/61WVAB192 | A2FM160/61WVAB192J | A2FM160/61WVZB192 | A2FM160/61WVZB192J |
| A2FM160/61WVBB192 | A2FM160/61WVBB192J | A2FM160/61WVPB192 | A2FM160/61WVPB192J |
| A2FM160/61WPAB188 | A2FM160/61WPAB188J | A2FM160/61WPZB188 | A2FM160/61WPZB188J |
| A2FM160/61WPBB188 | A2FM160/61WPBB188J | A2FM160/61WPPB188 | A2FM160/61WPPB188J |
| A2FM160/61WVAB188 | A2FM160/61WVAB188J | A2FM160/61WVZB188 | A2FM160/61WVZB188J |
| A2FM160/61WVBB188 | A2FM160/61WVBB188J | A2FM160/61WVPB188 | A2FM160/61WVPB188J |
| A2FM180/61WPAB027 | A2FM180/61WPAB027J | A2FM180/61WPZB027 | A2FM180/61WPZB027J |
| A2FM180/61WPBB027 | A2FM180/61WPBB027J | A2FM180/61WPPB027 | A2FM180/61WPPB027J |
| A2FM180/61WVAB027 | A2FM180/61WVAB027J | A2FM180/61WVZB027 | A2FM180/61WVZB027J |
| A2FM180/61WVBB027 | A2FM180/61WVBB027J | A2FM180/61WVPB027 | A2FM180/61WVPB027J |
| A2FM180/61WPAB010 | A2FM180/61WPAB010J | A2FM180/61WPZB010 | A2FM180/61WPZB010J |
| A2FM180/61WPBB010 | A2FM180/61WPBB010J | A2FM180/61WPPB010 | A2FM180/61WPPB010J |
| A2FM180/61WVAB010 | A2FM180/61WVAB010J | A2FM180/61WVZB010 | A2FM180/61WVZB010J |
| A2FM180/61WVBB010 | A2FM180/61WVBB010J | A2FM180/61WVPB010 | A2FM180/61WVPB010J |
| A2FM180/61WPAB020 | A2FM180/61WPAB020J | A2FM180/61WPZB020 | A2FM180/61WPZB020J |
| A2FM180/61WPBB020 | A2FM180/61WPBB020J | A2FM180/61WPPB020 | A2FM180/61WPPB020J |
| A2FM180/61WVAB020 | A2FM180/61WVAB020J | A2FM180/61WVZB020 | A2FM180/61WVZB020J |
| A2FM180/61WVBB020 | A2FM180/61WVBB020J | A2FM180/61WVPB020 | A2FM180/61WVPB020J |
| A2FM180/61WPAB100 | A2FM180/61WPAB100J | A2FM180/61WPZB100 | A2FM180/61WPZB100J |
| A2FM180/61WPBB100 | A2FM180/61WPBB100J | A2FM180/61WPPB100 | A2FM180/61WPPB100J |
| A2FM180/61WVAB100 | A2FM180/61WVAB100J | A2FM180/61WVZB100 | A2FM180/61WVZB100J |
| A2FM180/61WVBB100 | A2FM180/61WVBB100J | A2FM180/61WVPB100 | A2FM180/61WVPB100J |
| A2FM180/61WPAB181 | A2FM180/61WPAB181J | A2FM180/61WPZB181 | A2FM180/61WPZB181J |
| A2FM180/61WPBB181 | A2FM180/61WPBB181J | A2FM180/61WPPB181 | A2FM180/61WPPB181J |
| A2FM180/61WVAB181 | A2FM180/61WVAB181J | A2FM180/61WVZB181 | A2FM180/61WVZB181J |
| A2FM180/61WVBB181 | A2FM180/61WVBB181J | A2FM180/61WVPB181 | A2FM180/61WVPB181J |
| A2FM180/61WPAB191 | A2FM180/61WPAB191J | A2FM180/61WPZB191 | A2FM180/61WPZB191J |
| A2FM180/61WPBB191 | A2FM180/61WPBB191J | A2FM180/61WPPB191 | A2FM180/61WPPB191J |
| A2FM180/61WVAB191 | A2FM180/61WVAB191J | A2FM180/61WVZB191 | A2FM180/61WVZB191J |
| A2FM180/61WVBB191 | A2FM180/61WVBB191J | A2FM180/61WVPB191 | A2FM180/61WVPB191J |
| A2FM180/61WPAB192 | A2FM180/61WPAB192J | A2FM180/61WPZB192 | A2FM180/61WPZB192J |
| A2FM180/61WPBB192 | A2FM180/61WPBB192J | A2FM180/61WPPB192 | A2FM180/61WPPB192J |
| A2FM180/61WVAB192 | A2FM180/61WVAB192J | A2FM180/61WVZB192 | A2FM180/61WVZB192J |
| A2FM180/61WVBB192 | A2FM180/61WVBB192J | A2FM180/61WVPB192 | A2FM180/61WVPB192J |
| A2FM180/61WPAB188 | A2FM180/61WPAB188J | A2FM180/61WPZB188 | A2FM180/61WPZB188J |
| A2FM180/61WPBB188 | A2FM180/61WPBB188J | A2FM180/61WPPB188 | A2FM180/61WPPB188J |
| A2FM180/61WVAB188 | A2FM180/61WVAB188J | A2FM180/61WVZB188 | A2FM180/61WVZB188J |
| A2FM180/61WVBB188 | A2FM180/61WVBB188J | A2FM180/61WVPB188 | A2FM180/61WVPB188J |
| A2FM200/63WPAB010 | A2FM200/63WPAB010J | A2FM200/63WPZB010 | A2FM200/63WPZB010J |
| A2FM200/63WPBB010 | A2FM200/63WPBB010J | A2FM200/63WPPB010 | A2FM200/63WPPB010J |
| A2FM200/63WVAB010 | A2FM200/63WVAB010J | A2FM200/63WVZB010 | A2FM200/63WVZB010J |
| A2FM200/63WVBB010 | A2FM200/63WVBB010J | A2FM200/63WVPB010 | A2FM200/63WVPB010J |
| A2FM250/60WPZB010 | A2FM250/60WPZB010J | A2FM250/60WVZB010 | A2FM250/60WVZB010J |
| A2FM250/60WPPB010 | A2FM250/60WPPB010J | A2FM250/60WVPB010 | A2FM250/60WVPB010J |
| A2FM250/60WPZB020 | A2FM250/60WPZB020J | A2FM250/60WVZB020 | A2FM250/60WVZB020J |
| A2FM250/60WPPB020 | A2FM250/60WPPB020J | A2FM250/60WVPB020 | A2FM250/60WVPB020J |
| A2FM250/60WPZB027F | A2FM250/60WPZB027FJ | A2FM250/60WVZB027F | A2FM250/60WVZB027FJ |
| A2FM250/60WPPB027F | A2FM250/60WPPB027FJ | A2FM250/60WVPB027F | A2FM250/60WVPB027FJ |
| A2FM250/60WPZB010F | A2FM250/60WPZB010FJ | A2FM250/60WVZB010F | A2FM250/60WVZB010FJ |
| A2FM250/60WPPB010F | A2FM250/60WPPB010FJ | A2FM250/60WVPB010F | A2FM250/60WVPB010FJ |
| A2FM250/60WPZB020F | A2FM250/60WPZB020FJ | A2FM250/60WVZB020F | A2FM250/60WVZB020FJ |
| A2FM250/60WPPB020F | A2FM250/60WPPB020FJ | A2FM250/60WVPB020F | A2FM250/60WVPB020FJ |
| A2FM250/60WPZB027H | A2FM250/60WPZB027HJ | A2FM250/60WVZB027H | A2FM250/60WVZB027HJ |
| A2FM250/60WPPB027H | A2FM250/60WPPB027HJ | A2FM250/60WVPB027H | A2FM250/60WVPB027HJ |
| A2FM250/60WPZB010H | A2FM250/60WPZB010HJ | A2FM250/60WVZB010H | A2FM250/60WVZB010HJ |
| A2FM250/60WPPB010H | A2FM250/60WPPB010HJ | A2FM250/60WVPB010H | A2FM250/60WVPB010HJ |
| A2FM250/60WPZB020H | A2FM250/60WPZB020HJ | A2FM250/60WVZB020H | A2FM250/60WVZB020HJ |
| A2FM250/60WPPB020H | A2FM250/60WPPB020HJ | A2FM250/60WVPB020H | A2FM250/60WVPB020HJ |
| A2FLM250/60WPZB027 | A2FLM250/60WPZB027J | A2FLM250/60WVZB027 | A2FLM250/60WVZB027J |
| A2FLM250/60WPPB027 | A2FLM250/60WPPB027J | A2FLM250/60WVPB027 | A2FLM250/60WVPB027J |
| A2FLM250/60WPZB010 | A2FLM250/60WPZB010J | A2FLM250/60WVZB010 | A2FLM250/60WVZB010J |
| A2FLM250/60WPPB010 | A2FLM250/60WPPB010J | A2FLM250/60WVPB010 | A2FLM250/60WVPB010J |
| A2FLM250/60WPZB020 | A2FLM250/60WPZB020J | A2FLM250/60WVZB020 | A2FLM250/60WVZB020J |
| A2FLM250/60WPPB020 | A2FLM250/60WPPB020J | A2FLM250/60WVPB020 | A2FLM250/60WVPB020J |
| A2FLM250/60WPZB027F | A2FLM250/60WPZB027FJ | A2FLM250/60WVZB027F | A2FLM250/60WVZB027FJ |
| A2FLM250/60WPPB027F | A2FLM250/60WPPB027FJ | A2FLM250/60WVPB027F | A2FLM250/60WVPB027FJ |
| A2FLM250/60WPZB010F | A2FLM250/60WPZB010FJ | A2FLM250/60WVZB010F | A2FLM250/60WVZB010FJ |
| A2FLM250/60WPPB010F | A2FLM250/60WPPB010FJ | A2FLM250/60WVPB010F | A2FLM250/60WVPB010FJ |
| A2FLM250/60WPZB020F | A2FLM250/60WPZB020FJ | A2FLM250/60WVZB020F | A2FLM250/60WVZB020FJ |
| A2FLM250/60WPPB020F | A2FLM250/60WPPB020FJ | A2FLM250/60WVPB020F | A2FLM250/60WVPB020FJ |
| A2FLM250/60WPZB027H | A2FLM250/60WPZB027HJ | A2FLM250/60WVZB027H | A2FLM250/60WVZB027HJ |
| A2FLM250/60WPPB027H | A2FLM250/60WPPB027HJ | A2FLM250/60WVPB027H | A2FLM250/60WVPB027HJ |
| A2FLM250/60WPZB010H | A2FLM250/60WPZB010HJ | A2FLM250/60WVZB010H | A2FLM250/60WVZB010HJ |
| A2FLM250/60WPPB010H | A2FLM250/60WPPB010HJ | A2FLM250/60WVPB010H | A2FLM250/60WVPB010HJ |
| A2FLM250/60WPZB020H | A2FLM250/60WPZB020HJ | A2FLM250/60WVZB020H | A2FLM250/60WVZB020HJ |
| A2FLM250/60WPPB020H | A2FLM250/60WPPB020HJ | A2FLM250/60WVPB020H | A2FLM250/60WVPB020HJ |
| A2FM355/60WPZH017 | A2FM355/60WPZH017J | A2FM355/60WVZH017 | A2FM355/60WVZH017J |
| A2FM355/60WPPH017 | A2FM355/60WPPH017J | A2FM355/60WVPH017 | A2FM355/60WVPH017J |
| A2FM355/60WPZH010 | A2FM355/60WPZH010J | A2FM355/60WVZH010 | A2FM355/60WVZH010J |
| A2FM355/60WPPH010 | A2FM355/60WPPH010J | A2FM355/60WVPH010 | A2FM355/60WVPH010J |
| A2FM355/60WPZH017F | A2FM355/60WPZH017FJ | A2FM355/60WVZH017F | A2FM355/60WVZH017FJ |
| A2FM355/60WPPH017F | A2FM355/60WPPH017FJ | A2FM355/60WVPH017F | A2FM355/60WVPH017FJ |
| A2FM355/60WPZH010F | A2FM355/60WPZH010FJ | A2FM355/60WVZH010F | A2FM355/60WVZH010FJ |
| A2FM355/60WPPH010F | A2FM355/60WPPH010FJ | A2FM355/60WVPH010F | A2FM355/60WVPH010FJ |
| A2FM355/60WPZH017H | A2FM355/60WPZH017HJ | A2FM355/60WVZH017H | A2FM355/60WVZH017HJ |
| A2FM355/60WPPH017H | A2FM355/60WPPH017HJ | A2FM355/60WVPH017H | A2FM355/60WVPH017HJ |
| A2FM355/60WPZH010H | A2FM355/60WPZH010HJ | A2FM355/60WVZH010H | A2FM355/60WVZH010HJ |
| A2FM355/60WPPH010H | A2FM355/60WPPH010HJ | A2FM355/60WVPH010H | A2FM355/60WVPH010HJ |
| A2FLM355/60WPZH017 | A2FLM355/60WPZH017J | A2FLM355/60WVZH017 | A2FLM355/60WVZH017J |
| A2FLM355/60WPPH017 | A2FLM355/60WPPH017J | A2FLM355/60WVPH017 | A2FLM355/60WVPH017J |
| A2FLM355/60WPZH010 | A2FLM355/60WPZH010J | A2FLM355/60WVZH010 | A2FLM355/60WVZH010J |
| A2FLM355/60WPPH010 | A2FLM355/60WPPH010J | A2FLM355/60WVPH010 | A2FLM355/60WVPH010J |
| A2FLM355/60WPZH017F | A2FLM355/60WPZH017FJ | A2FLM355/60WVZH017F | A2FLM355/60WVZH017FJ |
| A2FLM355/60WPPH017F | A2FLM355/60WPPH017FJ | A2FLM355/60WVPH017F | A2FLM355/60WVPH017FJ |
| A2FLM355/60WPZH010F | A2FLM355/60WPZH010FJ | A2FLM355/60WVZH010F | A2FLM355/60WVZH010FJ |
| A2FLM355/60WPPH010F | A2FLM355/60WPPH010FJ | A2FLM355/60WVPH010F | A2FLM355/60WVPH010FJ |
| A2FLM355/60WPZH017H | A2FLM355/60WPZH017HJ | A2FLM355/60WVZH017H | A2FLM355/60WVZH017HJ |
| A2FLM355/60WPPH017H | A2FLM355/60WPPH017HJ | A2FLM355/60WVPH017H | A2FLM355/60WVPH017HJ |
| A2FLM355/60WPZH010H | A2FLM355/60WPZH010HJ | A2FLM355/60WVZH010H | A2FLM355/60WVZH010HJ |
| A2FLM355/60WPPH010H | A2FLM355/60WPPH010HJ | A2FLM355/60WVPH010H | A2FLM355/60WVPH010HJ |
| A2FM500/60WPZH017 | A2FM500/60WPZH017J | A2FM500/60WVZH017 | A2FM500/60WVZH017J |
| A2FM500/60WPPH017 | A2FM500/60WPPH017J | A2FM500/60WVPH017 | A2FM500/60WVPH017J |
| A2FM500/60WPZH010 | A2FM500/60WPZH010J | A2FM500/60WVZH010 | A2FM500/60WVZH010J |
| A2FM500/60WPPH010 | A2FM500/60WPPH010J | A2FM500/60WVPH010 | A2FM500/60WVPH010J |
| A2FM500/60WPZH017F | A2FM500/60WPZH017FJ | A2FM500/60WVZH017F | A2FM500/60WVZH017FJ |
| A2FM500/60WPPH017F | A2FM500/60WPPH017FJ | A2FM500/60WVPH017F | A2FM500/60WVPH017FJ |
| A2FM500/60WPZH010F | A2FM500/60WPZH010FJ | A2FM500/60WVZH010F | A2FM500/60WVZH010FJ |
| A2FM500/60WPPH010F | A2FM500/60WPPH010FJ | A2FM500/60WVPH010F | A2FM500/60WVPH010FJ |
| A2FM500/60WPZH017H | A2FM500/60WPZH017HJ | A2FM500/60WVZH017H | A2FM500/60WVZH017HJ |
| A2FM500/60WPPH017H | A2FM500/60WPPH017HJ | A2FM500/60WVPH017H | A2FM500/60WVPH017HJ |
| A2FM500/60WPZH010H | A2FM500/60WPZH010HJ | A2FM500/60WVZH010H | A2FM500/60WVZH010HJ |
| A2FM500/60WPPH010H | A2FM500/60WPPH010HJ | A2FM500/60WVPH010H | A2FM500/60WVPH010HJ |
| A2FLM500/60WPZH017 | A2FLM500/60WPZH017J | A2FLM500/60WVZH017 | A2FLM500/60WVZH017J |
| A2FLM500/60WPPH017 | A2FLM500/60WPPH017J | A2FLM500/60WVPH017 | A2FLM500/60WVPH017J |
| A2FLM500/60WPZH010 | A2FLM500/60WPZH010J | A2FLM500/60WVZH010 | A2FLM500/60WVZH010J |
| A2FLM500/60WPPH010 | A2FLM500/60WPPH010J | A2FLM500/60WVPH010 | A2FLM500/60WVPH010J |
| A2FLM500/60WPZH017F | A2FLM500/60WPZH017FJ | A2FLM500/60WVZH017F | A2FLM500/60WVZH017FJ |
| A2FLM500/60WPPH017F | A2FLM500/60WPPH017FJ | A2FLM500/60WVPH017F | A2FLM500/60WVPH017FJ |
| A2FLM500/60WPZH010F | A2FLM500/60WPZH010FJ | A2FLM500/60WVZH010F | A2FLM500/60WVZH010FJ |
| A2FLM500/60WPPH010F | A2FLM500/60WPPH010FJ | A2FLM500/60WVPH010F | A2FLM500/60WVPH010FJ |
| A2FLM500/60WPZH017H | A2FLM500/60WPZH017HJ | A2FLM500/60WVZH017H | A2FLM500/60WVZH017HJ |
| A2FLM500/60WPPH017H | A2FLM500/60WPPH017HJ | A2FLM500/60WVPH017H | A2FLM500/60WVPH017HJ |
| A2FLM500/60WPZH010H | A2FLM500/60WPZH010HJ | A2FLM500/60WVZH010H | A2FLM500/60WVZH010HJ |
| A2FLM500/60WPPH010H | A2FLM500/60WPPH010HJ | A2FLM500/60WVPH010H | A2FLM500/60WVPH010HJ |
| A2FLM710/60WPZH017 | A2FLM710/60WPZH017J | A2FLM710/60WVZH017 | A2FLM710/60WVZH017J |
| A2FLM710/60WPPH017 | A2FLM710/60WPPH017J | A2FLM710/60WVPH017 | A2FLM710/60WVPH017J |
| A2FLM710/60WPZH010 | A2FLM710/60WPZH010J | A2FLM710/60WVZH010 | A2FLM710/60WVZH010J |
| A2FLM710/60WPPH010 | A2FLM710/60WPPH010J | A2FLM710/60WVPH010 | A2FLM710/60WVPH010J |
| A2FLM710/60WPZH017 | A2FLM710/60WPZH017J | A2FLM710/60WVZH017 | A2FLM710/60WVZH017J |
| A2FLM710/60WPPH017 | A2FLM710/60WPPH017J | A2FLM710/60WVPH017 | A2FLM710/60WVPH017J |
| A2FLM710/60WPZH010 | A2FLM710/60WPZH010J | A2FLM710/60WVZH010 | A2FLM710/60WVZH010J |
| A2FLM710/60WPPH010 | A2FLM710/60WPPH010J | A2FLM710/60WVPH010 |
A2FLM710/60WVPH010J |
- تم تصميم محركات A2FM للاستخدام في الدوائر المفتوحة والمغلقة.
- يجب تنفيذ تخطيط المشروع وتركيب وحدات المكبس المحورية من قبل أفراد مؤهلين.
- قبل استخدام وحدة المكبس المحورية ، اقرأ دليل التعليمات المقابل تمامًا. متاح عند الطلب من Bosch Rexroth.
- خطر الحروق من وحدة المكبس المحورية أثناء وبعد فترة وجيزة من التشغيل. يجب اتخاذ تدابير السلامة المناسبة (على سبيل المثال ارتداء ملابس واقية).
- قد تختلف خصائص وحدة المكبس المحورية بسبب ظروف التشغيل المختلفة (ضغط التشغيل ، درجة حرارة السائل).
- منافذ خط العمل:
تم تصميم المنافذ والموضوعات التثبيت لتحقيق أقصى قدر من الضغط المحدد. يجب أن تضمن الشركة المصنعة للماكينة أو النظام أن عوامل أمان عناصر التوصيل والخطوط تلبي ظروف التشغيل المحددة (الضغط ، التدفق ، الزيت الهيدروليكي ، درجة الحرارة).
• منافذ خطوط العمل ومنافذ الوظائف مخصصة للخطوط الهيدروليكية فقط.
- يجب اتباع البيانات والتعليمات الواردة هنا.
- لا يمكن الموافقة على المنتج كمكون يتبع مفهوم السلامة العامة لآلات ISO13849.
- استخدم عزم الدوران التشديد التالي:
· الموصل:
راجع تعليمات الشركة المصنعة لتصميم عزم الدوران للتجهيزات المستخدمة.
· تصاعد البراغي:
بالنسبة لتصاعد البراغي مع خيوط مترية ISO وفقًا لـ DIN13 والخيوط وفقًا لـ ASMEB1.1 ، نوصي بالتحقق من عزم الدوران في العلب الفردية وفقًا لـ VDI2230.
· ثقب الخيوط لوحدة المكبس المحوري:
أقصى عزم الدوران المسموح به هو الحد الأقصى لقيمة الثقوب الملولبة ويجب عدم تجاوزها.
· قفل مسامير:
بالنسبة إلى مسامير القفل المعدنية التي يتم توفيرها بوحدة المكبس المحورية ، يجب استخدام عزم الدوران MV المطلوب لمسمار القفل.
احتياطات التثبيت
أثناء التكليف والتشغيل ، يجب دائمًا ملء وحدة المكبس المحورية بالزيت الهيدروليكي والتهوية بالهواء. يجب أيضًا ملاحظة الاحتياطات المذكورة أعلاه بعد فترة طويلة نسبيًا من عدم النشاط ، لأن وحدة المكبس المحورية قد تستنزف الزيت الهيدروليكي مرة أخرى في الخزان عبر الخط الهيدروليكي.
لا سيما في موضع تثبيت "عمود النقل" ، يجب تنفيذ ملء الزيت والعادم بدقة ، وإلا سيكون هناك مخاطر مثل التشغيل الخالي من النفط.
يجب استنزاف زيت الصرف في سكن المضخة إلى الخزان من خلال أعلى منافذ التصريف (T1 ، T2).
بالنسبة لمجموعات الأجهزة المتعددة ، تأكد من عدم تجاوز الضغط المقابل لكل جهاز. عندما يوجد ضغط تفاضلي في موانئ الصرف في الجهاز ، يجب استبدال خط التصريف الشائع بحيث لا يتم تجاوز الحد الأدنى للضغط المسموح به لجميع المعدات المتصلة تحت أي ظرف من الظروف. إذا لم يكن ذلك ممكنًا ، فيجب وضع خط تصريف منفصل إذا لزم الأمر.
للحصول على قيم ضوضاء مواتية ، يجب فصل جميع خطوط التوصيل بعناصر مرنة ويجب تجنب التثبيت فوق الخزان.
في ظل جميع ظروف التشغيل ، يجب أن يؤدي خط التصريف إلى نقطة أقل من مستوى الزيت في الخزان.
فيديو
فيديو
فيديو
